Specification:
Type:
Dimensions:
Weight:
Product Details
Applications
For window film reinforcement on mobile phone, wine, gift, and cosmetic boxes. Compatible with 200–500 g/m² cardboard, ≤7 mm corrugated board, and ≤250 g/m² kraft paper for automatic gluing, patching, and sheet stacking, with optional film slitting.
Key Advantages
1. High Efficiency – Up to 8000 sheets/h, processes 200–500 g/m² cardboard and ≤7 mm corrugated board for rapid delivery of large orders.
2. Two Specifications Available to Meet Actual Production Needs – Two models 1020/1200 optional, max. paper size 1080×630 mm / 1200×720 mm, min. paper size 140×140 mm. Compatible with diverse production from small cosmetic boxes to large wine boxes.
3. Fully Automatic Inline Operation – Automatic gluing, patching, sheet stacking, optional film slitting; bubble‑free lamination, reduced manual intervention, improved consistency.
4. Precision Patching – Supports 0.05–0.20mm film, min. patch size 60×60mm / 80×60mm optional, accurate positioning, strong adhesion.
Typical Applications
This machine is applied to the window (or non-window) film reinforcement process for the following packaging paper products:
· Consumer electronics: Mobile phone boxes, headphone boxes, smartwatch boxes
· Wine & gifts: Liquor boxes, wine boxes, tea gift boxes, premium gift boxes
· Cosmetics & personal care: Cosmetic boxes, skincare gift boxes, perfume boxes
· Food & daily products: Napkin boxes, cake boxes, milk cartons, snack boxes
· Other paper products: Greeting cards, calendar covers, stationery boxes, garment boxes
